Overview
The EAE KNX Mona Card Holder is an energy-saving solution designed specifically for hotel guest rooms. With a sleek glass surface and contactless RFID technology, the Mona Card Holder enables efficient room energy management by detecting Mifare 13.56 MHz cards. In addition to card detection, it can be equipped with up to six programmable buttons, allowing full KNX control for functions such as switching, dimming, scene calls, and more.
Key Features
- Monoblock glass front panel design
- Compatible with Mifare 13.56 MHz RFID cards
- Contactless reading with up to 50 mm detection distance
- Avoids mechanical wear and card deformation
- Up to 6 independent programmable buttons
- Supports KNX functions: switching, dimming, scene control, value transmission
- LED indicator for visual feedback
- Flush-mounted installation
- Device powered directly via KNX bus
Specifications
- Type of Protection: IP20 – EN 60 529
- Safety Class: II – EN 61 140
- Power Supply: 21V…30V DC via the KNX bus
- Current Consumption: ≤ 25 mA
- Connection: KNX Bus Connection
- Operating Elements: Hotel Card, LED Indicator
- Card Compatibility: Mifare 13.56 MHz
- Detection Distance: Up to 50 mm
- Installation: Flush Mounted
- Ambient Temperature: 0°C to +50°C
- Max Humidity: 95% RH, no condensation
- Dimensions (Front): 90 x 100 mm
- Surface Mount Depth: 12 mm
- Flush Mount Depth: 18.8 mm
- Weight: 0.10 kg
- Box Material: Glass front, polycarbonate flush-mounted part
- Color Options: Black or White glass front; Black polycarbonate body
- Certification: CE compliant with EMC directive
Application Scenarios
The Mona Card Holder is ideal for hotel rooms, ensuring energy is used only when a valid room card is detected. It promotes sustainability and cost-efficiency while offering an elegant, touch-free guest experience. Programmable buttons add flexibility for additional in-room automation.
Why Choose the EAE Mona Card Holder?
Combining aesthetics with intelligent KNX control, the EAE Mona Card Holder is a must-have for modern hospitality environments. Its contactless RFID design and programmable functionality make it a versatile and durable component of any smart hotel solution.
