Akuvox X910 Smart Door Phone – Sleek Intercom with 2K Camera

Overview

The Akuvox X910 is a premium SIP video door phone designed for modern residences and luxury villas. With its dark, minimalistic finish and single-button design, it delivers top-tier smart access functionality while elevating the building’s overall aesthetic. Featuring dual cameras, 2K ultra-wide video, and multiple unlock methods, the X910 ensures secure and seamless communication between visitors and residents.


Key Features

  • Single-button design with sleek dark-tone aluminum housing
  • 5MP main camera + 2MP auxiliary camera with automatic lighting
  • Ultra-wide video capture up to 2000×2000 resolution
  • Supports multiple unlock methods including card and PIN
  • Two-way audio with echo cancellation and noise suppression
  • Compatible with third-party NVRs and video systems
  • Wall-mounted installation with IK08 & IP66 protection

Specifications

Physical & Power

  • Front Panel: Aluminum
  • Main Camera: 5MP with automatic lighting
  • Auxiliary Camera: 2MP with automatic lighting
  • Button: 1 call button
  • Light Sensor & Motion Sensor: Supported
  • Wiegand Port, RS485 Port, Line Out: Supported
  • RF Card Reader: 13.56MHz, NFC
  • Relays Out: 2 | Inputs: 2
  • Microphone: 1 | Speaker: 1
  • Ethernet: RJ45, 10/100Mbps adaptive
  • Power: IEEE 802.3at PoE / 12V DC
  • Protection Rating: IP66 / IK08
  • Installation: Wall-mounted
  • Dimensions: 192x70x27 mm
  • Working Temp: -40°C ~ +55°C | Humidity: 10~90%

Audio

  • SIP v1 & v2 (RFC2543, RFC3261)
  • Audio Codecs: G.711a, G.711μ, G.722
  • DTMF: In-band, RFC2833, SIP Info
  • Echo Cancellation, Voice Activation Detection
  • Comfort Noise Generator

Video

  • Sensor: 1/2.78” CMOS
  • Video Resolution: Up to 2000×2000 (2K)
  • Codecs: H.264 | Frame Rate: 30fps
  • Viewing Angle: 150°(H) / 116°(V)
  • Auto-night Mode with LED Illumination
  • Compatible with 3rd-party NVRs

Networking & Protocols

  • Protocols: IPv4, HTTP, HTTPS, FTP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

Door Entry & Management

  • Relay Control via DTMF Tones
  • Camera Always Active
  • White Balance: Auto | Minimum Illumination: 0.1LUX
  • Multi-way Unlock: Face, Card, PIN, BLE

Deployment & Maintenance

  • Auto-Provisioning & Web Portal Management
  • Firmware Upgrade & Configuration Backup/Restore
  • System & Access Logs Export

Application Scenarios

  • Ideal for villas, luxury residences, and high-end commercial buildings
  • Supports remote door entry over internet or IP-PBX systems

Why Choose the Akuvox X910?

The Akuvox X910 is the ideal choice for users who want a sophisticated door entry solution without compromising on design. Its 2K wide-angle video, robust construction, and integration capabilities make it a perfect fit for villas, high-end apartments, and office entrances. Additionally, proactive parcel protection features help secure unattended deliveries, making daily life smarter and more convenient.

Akuvox X910 Smart SIP Door Phone front view
